LQ231U1LW32 Sharp 23.1" LCM 1600×1200RGB 500cd/m² INDUSTRIAL LCD DISPLAY

  • 1
  • 2
  • 3

Brand Name : Sharp

Model Number : LQ231U1LW32

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 200PCS

Delivery Time : 1-2DAYS

Packaging Details : 2 pcs / box 11 Kgs 630×515×195 mm (L×W×H)

Diagonal Size : 23.1"

Model : LQ231U1LW32

Luminance : 500cd/m²

Pixel Format : 1600×1200RGB

Bezel Area : 476.4(H)×358.8(V) mm

Type : a-Si TFT-LCD , LCM

Outline Dim. : 530(H)×431.5(V) ×24.9(D) mm

Operating Mode : ASV, Normally Black, Transmissive [Panelook copyright, copy is strictly prohibited] IPS Family: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich VA Family: ASV, HVA, MVA, PVA, SVA, UV²A, VA

Light Source : WLED , 50K hours , With LED Driver

Environment : Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -25 ~ 65 °C

Contact Now

LQ231 Series LQ231U1LW32 LQ231U1LW31 LQ231U1LW21

Sharp LQ231U1LW32 Optical Features

Basic Information : Luminance (cd/m²) Viewing Angle (L/R/U/D) Response Time (ms)
500 (Typ.) 85/85/85/85 (Min.)(CR≥10) 12 (Typ.)(Tr+Td); 8 (Typ.)(G to G)
Best View on Display Mode Contrast Ratio
Symmetry ASV, Normally Black, Transmissive 600 : 1 (Typ.) (Transmissive)
Dispaly Color : Color Temperature Display Colors White Coordinate
7992K 16.7M (8-bit) X:0.292; Y:0.315
1931 Color Gamlt : NTSC Ratio sRGB Coverage Adobe RGB Coverage
62% 80% 63%
DCI-P3 Coverage Rec.2020 Coverage Remarks
65% 47% sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Variation : 1.33 (Max.)(9 Points)

Sharp LQ231U1LW32 Mechanical Features

Panel Size : 23.1"
Pixel Features : Pixel Format Pixel Configuration Pixel Pitch (mm) Dot Pitch (mm)
1600(RGB)×1200 [UXGA] RGB Vertical Stripe 0.294×0.294 [86PPI] 0.098×0.294
Mechanical Size : Active Area (mm) Bezel Area (mm) Outline Dimension (mm) Outline Depth (mm)
470.4(H) × 352.8(V) 476.4(H) × 358.8(V) 530(H) × 431.5(V) 23.9/24.9 (Typ./Max.) mm
Outline Features : Form Factor Orientation Aspect Ratio Shape Style
Flat Rectangle Landscape type 4:3 (H:V)
Mounting : Face mounting holes (4-Ф4.5) on left, right bezel
Other Detail : Weight Panel Cover Treatment
4.50Kgs (Max.) - Antiglare (Haze 40%), Hard coating (2H)

Sharp LQ231U1LW32 Backlight Features

Lamp Features: Type Position Quantity Shape Life(Hours) Lamp Exchange
WLED Edge light type - - 50K(Typ.) -
Interface Features : Position Backlight Driver Type
- With LED Driver Connector
Interface Detail : Brand Model Pin Pitch Pin Amount Quantity Configuration
JST S12B-PH-SM4-TB 2.0 mm 12 pins 1 pcs
Driver Electrical : Voltage Supply Current Supply Power Consumption
12.0V (Typ.) 5.0/5.8A (Typ./Max.) -

Sharp LQ231U1LW32 Interface Features

Panel Driving Electrical : Voltage Supply Current Supply Power
5.0V (Typ.) 1.10/1.80A (Typ./Max.) -
Interface Features : Position Signal Type
- OpenLDI Connector
Connector Detail : Brand Model Pin Pitch Pin Amount Quantity Configuration
JAE FI-WE31P-HFE 1.25 mm 31 pins 1 pcs

LQ231U1LW32 supports display 1600(RGB)×1200 (UXGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 470.4(W)×352.8(H) mm, outline size of 530(W)×431.5(H)×24.9(D) mm, viewing area size of 476.4(W)×358.8(H) mm, with surface treament of Antiglare (Haze 40%), Hard coating (2H), net weight of 4.50Kgs (Max.). As a ASV, Normally Black, Transmissive LCM product, LQ231U1LW32 can provides 500 cd/m² display brightness 600:1 transimissive contrast ratio, 85/85/85/85 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 12 (Typ.)(Tr+Td); 8 (Typ.)
